IFE T3 horizontal moving walks help people move quickly and efficiently through congested areas while allowing large luggage carts to pass through with ample space.
| Specification | T3 | |||
| Lifting height range/m | -- | |||
| Use segment length/m | 100 | |||
| Tilt angle/° | 0/6 | |||
| Nominal width/mm | 1000/1200/1400 | |||
| Nominal speed/m/s | 0.5/0.65 | |||
| Applicable environment | Indoor/Outdoor | |||
| The type of work | Public transport type | |||
| Handrail structure | Vertical armrests | |||
| Stainless steel diagonal armrest | ||||
| Drag method | VVVF | |||
| Startup mode | Frequency conversion low speed Frequency conversion self-starting | |||
| Number of horizontal steps as standard | H≤6m | -- | ||
| H>6m | -- | |||
| Pedal depth/mm as standard | 400 | |||
| Additional brakes | H≤6m | Yes | ||
| H>6m | Yes | |||
| Truss deflection | ≤1/1000 | |||
| Safety factor for moving parts | ≥5 | |||
